ATMOR Multipoint Instantaneous Water Heater
designed to supply continuous hot water on demend. Ideal for
open vented point-of-use applications such as showers and kitchen taps.
STANDARD FEATURES:
- - Fully automatic operation
- - Auto Shut-off (at 55°C)
- - User friendly buttons and switches
- - Heating Chamber made of High Grade Composite Materials
- - Internationally approved aesthetic and engineering design
| TECHNICAL SPECIFICATIONS: | |
|---|---|
| Technology / Standard | GERMAN STANDARD TECHNOLOGY |
| Type | Electric Instantaneous (demand) Water Heater |
| Operation | Fully Automatic |
| Activating Mechanism | Diaphragm Type |
| Temperature Selection | Three-way temperature selection |
| Safety | Auto-thermal cut-off at 52°C to 55°C; final cut-off at 80°C ±10% |
| Application | For open vented point-of-use application (e.g. shower) |
| Voltage | 220-240 VAC |
| Power Rating | 3.5 Kilowatts |
| Cycles | 50 Hz ~ 60 Hz |
| Phase | Single Phase |
| Power / Heat Setting | Low: 1.5 KW | Med: 2.0 KW | High: 3.5 KW |
| Kilowatt Loading | 220 VAC; 3.5 KW | 230 VAC; 3.5 KW | 240 VAC; 3.8 KW |
| Recommended Cable Size | 2.5/4 sq. mm |
| Recommended Circuit Breaker Rating | 30 Amperes |
| Cable | Top right and Top left |
| Height | 190 mm |
| Width | 300 mm |
| Depth | 110 mm |
| Inlet / Outlet Connection | 15 mm (1/2 compression inlet connection) |
| Flow Rate | 4 Liters/Minute (1.05 Gallons/Minute) @ 12°C Temp. Rise |
| Minimum Activating Pressure | 2.5 PSI (Pounds per Square Inch) |
| Operating Water Pressure | 0.3 – 7 BAR (S-100 PSI) |
| Accessories | Tele-shower Set with Riser Bar/Inlet Connection Fittings |
| Manufacturer | ATMOR Industries |
| Standard /Certification | ISO 9002, CE, BEAD, TUV, UL Listed |
